- Original article
- Open Access
Development of a core SNP arrays based on the KASP method for molecular breeding of rice
Rice volume 12, Article number: 21 (2019)
The development and utilization of genetic markers play a pivotal role in marker-assisted breeding of rice cultivars during pyramiding of valuable genes. Among molecular markers, SNPs have become the most promising due to their wide distribution within genomes and suitability for high -throughput automated genotyping. Although metadata of SNPs have been identified via next generation sequencing in rice, a large gap between the development of SNP markers and the application in breeding still exists. To promote the application of SNP markers based on the KASP (Kompetitive Allele-Specific PCR) method in rice breeding, a set of core SNP arrays was built via the screening of SNP databases and literature resources based on the KASP method.
Five hundred and ninety six SNPs classified into eight subsets including quality control, indica-indica variation, highly polymorphic, functional genes, key genes targeting sites, gene cloned region, important trait associated and gap filling sites were chosen to design KASP primers and 565 out of them were successfully designed, and the assay design success rate was 94.8%. Finally, 467 out of the 565 successfully-designed SNPs can display diversity at the loci were used to develop a set of core SNP arrays. To evaluate the application value of the core SNP markers in rice breeding, 481 rice germplasms were genotyped with three functional KASP markers designed from the sequences of GBSSI, SSIIa, and Badh2 from the core SNP arrays for estimation of their grain quality performance. Eighteen rice lines, including Xiangwanxian 13, Basmati 370, Ruanhua A, and PR 33319–9–1-1-5-3-5-4-1, harbor all three favorable alleles. The core KASP arrays were also used for rice germplasm assessment, genetic diversity and population evaluation. Four hundred and eighty-one rice germplasms were divided into 3 groups: POP1, POP2 and POP3. POP1 and POP2 were indica rice subgroups consisting of 263 and 186 rice germplasms, respectively. POP3 was a japonica rice subgroup consisting of 32 rice germplasms. The average FST value for the three subgroups was 0.3501; the FST value of POP1 and POP3 was the largest (0.5482), while that of POP1 and POP2 was the smallest (0.0721). The results showed that the genetic distance between the japonica and indica rice subspecies was large, indicating that the core SNP markers were effective at discriminating the population structure of the germplasms. Finally, the core KASP arrays were used for association analysis with milled grain traits. A total of 31 KASP markers were significantly associated (P < 0.01) with ML and the LWR. Among the 31 markers, 13 were developed based on cloned genes or on identified loci related to yield traits. Notably, several KASP markers associated with grain quality were also found to be associated with brown planthopper resistance or green leafhopper resistance simultaneously.
The core KASP arrays developed in our study were efficient and versatile for rice germplasm assessment, genetic diversity and population evaluation and are valuable for promoting SNP molecular breeding in rice. Our study demonstrated that useful assays combined with molecular breeding can be exploited for important economic trait improvement in rice breeding.
Cultivated rice (Oryza sativa L.) is one of the most important crops and supplies food to approximately half of the human global population (Chen et al. 2014). Molecular marker-assisted selection (MAS), combined with conventional breeding approaches, enables breeders to identify individual genotypes that are precisely associated with different economically important traits, which can dramatically improve rice breeding efficiency (Tian et al. 2010). The development and utilization of genetic markers play a pivotal role in marker-assisted breeding of rice cultivars during pyramiding of valuable genes. High polymorphism, codominant inheritance, high density, high throughput, and easy automation and data exchange are the characteristics of ideal DNA markers (Tripathi et al. 2016). In addition, making full use of cloned genes that control agronomic traits or highly reliable quantitative trait loci information to develop molecular markers that are closely related to traits is also an important for improving the efficiency of molecular breeding.
Since the discovery of single-nucleotide polymorphisms (SNPs) in 1994, SNPs have been widely used in many fields, such as biology, agriculture, medicine, and biological evolution. Among molecular markers, SNPs have become the most promising due to their wide distribution within genomes and suitability for high-throughput automated genotyping. High-throughput sequencing technology has greatly advanced the discovery of SNP markers. A total of 408,898 candidate DNA polymorphisms (SNPs and/or insertions/deletions (InDels) were identified via comparative analysis of the draft genome sequences of the rice cultivars Nipponbare (japonica) and 93–11 (indica) (Feltus et al. 2004) under the support of the International Rice Genome Sequencing Project 2005. One hundred sixty thousand nonredundant SNPs (McNally et al. 2009) were identified by sequencing 100 Mb of specific reference genome sequences of 20 different cultivars, including local cultivars. Since 2011, rice resequencing projects have also provided an abundance of information about rice SNP markers, and databases have been constructed for querying and determining rice SNP loci, e.g., the Gramene database (http://ensembl.gramene.org/genome_browser/index.html), the Rice Diversity Project database (https://ricediversity.org/), the Rice Genome Annotation Project database (http://rice.plantbiology.msu.edu/), and the Rice SNP-Seek Database (http://snp-seek.irri.org). In 2015, SNPs and small-fragment InDels of 2859 rice genomes of good quality were obtained via the genome-wide resequencing of 3000 rice resources worldwide (Alexandrov et al. 2015). These genomic variation data were used to compile a comprehensive SNP and InDel polymorphism sub-database for rice functional genomics breeding. Moreover, in recent years, via quantitative trait loci (QTL) mapping, gene mapping, and genome-wide association studies (GWASs), researchers have also discovered a large number of genetic loci that contribute to important agronomic traits in rice. More than 800 loci associated with development, yield, quality, and biotic and abiotic stress have been cloned or finely mapped (Jiang et al. 2012, Jiang et al. 2012, Chen et al. 2013). These reported SNPs, genes and genetic loci information provide a reliable basis for the application of SNP markers in rice molecular breeding.
However, a large gap between the development of SNP markers and the application of rice breeding still exists. First, the current SNP databases provide a large amount of SNP information, including redundant information, and it is difficult for breeders to quickly obtain useful SNPs. For example, the Rice 3 K project provides more than 18 million different types of SNP information; this amount actually exceeds that possible for breeders to analyze. Therefore, it is important that the classification of core SNPs represents key information. Second, the relationships between a large number of SNPs and reported genes or genetic loci are not clear. There is a chronic shortage of functional, diagnostic or tightly linked SNP markers for use in molecular breeding. Currently, only a few diagnostic SNP markers are used in rice breeding, e.g., Wx, ALK, Pikh, GS3, GW5, and CHALK5, and it is difficult to meet the needs of molecular breeding to improve more important agronomic traits. Third, the methods of SNP detection are not flexible and adaptable to the changing demands of end-users. For example, hybrid-based SNP chips can accommodate a large amount of locus genotyping at one time, but the cost of detection is high; in addition, it is difficult to analyze the genotypes of various individual plants derived from genetically separate populations. Cleaved amplified polymorphic sequence (CAPS) markers can also be used for SNP allelic genotyping (Chen et al. 2009), but producing high-throughput genotyping results is difficult because of the inefficiency of the enzyme digestion system. The high-resolution melting (HRM) method based on DNA melting temperature analysis to detect SNP alleles strongly depends on complex multiplex PCR, which can easily lead to false positives. Sequencing is the most direct and accurate method for SNP detection, but it is expensive and requires professional bioinformatics analysis. Therefore, continued development of core SNP markers that are both closely related to agronomic traits and suitable for different needs is highly valuable.
Kompetitive Allele-Specific PCR (KASP) is a detection method that can type SNPs and InDels at specific sites. With respect to genotyping, KASP is based on terminal fluorescence reading, similar to the basis of TaqMan probe detection. Each method uses two-color fluorescence to detect individual samples of different genotypes at a single site; different fluorescent products reflect different DNA templates. For KASP tests, a SNP- or Indel-specific KASP assay mixture (specific primer mixture), KASP Master Mix (general mixture) and DNA samples are mixed together for thermal cycling, after which the fluorescence is read by laser scanning at the end point. KASP-SNP markers are highly accurate, inexpensive and highly flexible, and they have a high conversion rate and a wide range of applications. Several functional SNPs and InDels have been converted into functional markers (FMs) via KASP assays, greatly improving the speed and efficiency of selection in crop breeding programs (Neelam et al. 2013, Pariasca-Tanaka et al. 2015, Rasheed et al. 2016). Using the KASP method, researchers from the International Rice Research Institute (IRRI) have developed a total of 2015 SNP markers distributed throughout the genome for use in analyzing the genetic backgrounds of rice strains (Pariasca-Tanaka et al. 2015). However, few KASP-SNP functional or diagnostic markers have been reported, and classification of SNP arrays of high polymorphism and agronomic-associated traits is lacking. These factors are limiting the application of KASP-SNP markers in breeding procedures.
To promote the application of KASP-SNP markers in rice breeding, in the present study, eight subsets of SNP information were obtained by querying international rice genome databases and literature resources indica-indica variation, highly polymorphic, functional genes, key genes targeting sites, gene cloned region, important trait associated and gap filling sites. These SNP loci were converted into KASP markers, and 530 rice germplasms were genotyped with these SNP markers. Based on the results of genotyping, a set of core SNPs with high reliability was identified. To evaluate the application value of these core SNP markers in rice breeding, the population structure, allelic functional gene variation and correlations between SNP markers and grain characteristics were analyzed with the use of the identified core SNP markers. The findings of this study are valuable for promoting SNP molecular breeding in rice.
Conversion rate and genetic diversity of KASP marker assays
In the present study, KASP primers were designed from 565 out of 596 SNP sites successfully, and the assay design success rate was 94.8% (Table 1). The genotypes of 530 rice accessions were identified using the designed KASP primers. Among the 565 KASP markers, 98 were discarded because they could generate only one genotype call, thus displaying no diversity at the loci (Fig. 1a). A total of 467 markers showed at least 2 effective fluorescence signals; these SNPs were used to develop core KASP-SNP assays in our study (Fig. 1b). We analyzed the distribution of all the selected SNPs within the genome (Table 2). In general, the KASP markers were distributed relatively evenly, with an average density of 1.24 SNPs/Mb throughout all chromosomes, with the exception of chromosome 6. For visual viewing, a physical map of these markers was constructed via the mapping website Map Gene 2 Chromosome V2 (Fig. 2).
Marker assessment analysis revealed that the mean frequency, gene diversity, heterozygosity and polymorphism values were 0.80, 0.28, 0.01, and 0.24, respectively. Detailed analysis revealed that relatively high levels of polymorphism (measured by the minor allele frequency (MAF)) in the test range of rice accessions ranged mainly from 0.50 to 1.00 (Fig. 3a). The gene diversity ranged mainly from 0.01 to 0.60, with an average gene diversity of 0.28, and the heterozygosity across all loci ranged mainly from 0.00 to 0.93 (Fig. 3b,c). The PIC value ranged from 0.01 to 0.50, with an average value of 0.24 (Fig. 3d). Forty rare alleles (whose gene frequencies were less than 1%) were detected in 50 rice plants at 40 sites; these alleles accounted for 4.3% of all alleles. These rare alleles were distributed in 50 rice lines, 26 of which were collected from IRRI varieties, indicating the specific variation that exists within IRRI germplasms.
Classification of core SNP markers associated with agronomic traits
According to the physical position of the cloned gene or GWAS-identified locus, 244 markers were found to be related to important rice traits (yield, quality, resistance, root development, plant development and fertility) (Table 3). Yield-related markers were distributed across all the chromosomes, and quality-related markers were distributed mostly on chromosome 6. Markers related to plant development were distributed on chromosomes 1, 2, 3, 6, 7 and 11, and two fertility-related markers were located on chromosome 10. Of these 244 markers, 14 were developed based on the functional loci of cloned genes and could specifically distinguish between the functional alleles, 86 originated from polymorphic loci of the coding sequences of cloned genes and were considered gene targeting markers that can be used to track target genes, and 113 were considered gene overlapping markers because they originated from interval regions of cloned genes. In addition, 31 highly reliable trait-related SNP loci (based on previous GWAS results) were used to develop to KASP markers.
Notably, 14 functional SNP markers were characterized, including those related to grain quality, blast resistance, fertility and grain shape (Table 4). These functional SNP markers are responsible for corresponding traits and have significant value for superior allele screening and molecular breeding. Among these FMs, Wx, ALK and fgr can be used to improve eating quality, and Rf4 plays an important role in the molecular breeding of hybrid rice parents. Two dominant R genes, Pik and Pi2, were thought to provide broad-spectrum and high resistance to blast, so the pyramid of these two genes is valuable for breeding rice varieties that exhibit robust blast resistance. Two KASP-SNP markers, SK11.27979265 and SK06.10389729, were developed to distinguish between alleles of Pik and Pi2. GS3, a main QTL controlling grain weight and grain length, accounted for 80–90% of the variation in grain weight and grain length in a recombinant inbred line (RIL) population (Fan et al. 2006). On the basis of the A/C allele of exon 2 of the GS3 gene, the SNP marker SK03.16733441 was developed to distinguish between AA and CC variants, of which the AA allele is responsible for long-grain phenotypes.
Confirmation of KASP-SNP results via sanger sequencing
To evaluate the accuracy of the KASP-SNP genotyping results, Sanger sequencing and KASP genotyping primers were designed for the Pita gene. Pita is a blast resistance gene, and there is only one amino acid difference in the proteins of the two alleles encoded by the Pita locus; i.e., the 918th amino acid changes from alanine to serine, which is responsible for the change in resistance to susceptible. One SNP causes this amino acid difference: genotype G/G represents resistance, while T/T confers susceptibility. KASP genotyping was performed on 11 materials whose Pita genotypes are known, and the genotyping results were compared with those of Sanger sequencing. In terms of primer design, Sanger sequencing primers, Pita-F and Pita-R, were designed for amplifying 300 bp length sequences, which include SNP loci (Additional file 1: Table S1). Three primers were used for KASP genotyping: Pita-F, Pita-H and Pita-C. The first two primers accompany the FAM or HEX fluorescent markers, while Pita-C is a universal primer (Additional file 1: Table S1).
KASP primers were used to investigate 11 materials whose genotypes are known. The resistance group consisted of C296, C297, C298 and C304, all of which harbor the GG allele, while the susceptible group, comprising C258, C259 and C260, harbor the TT allele. The heterozygous group, which consisted of C275, C276, C277 and C278, had G/T alleles. The three groups were divided into different clusters according to fluorescence, as shown in Fig. 4a. The results are consistent with those of Sanger sequencing: genotypes G/G and T/T exhibited a single peak, while the heterozygous T/G genotype exhibited a double peak (Fig. 4b, c, d).
Application of core SNP markers for rice germplasm assessment, genetic diversity and population evaluation
Based on the genotyping results of 467 core SNP markers, the population structure of 481 rice germplasms was classified by Structure software. The population number K was set to 2–11, and each hypothetical K value was calculated five times. The ΔK of Evanno was maximal at K = 3. Therefore, the 481 rice germplasms were divided into 3 groups: POP1, POP2 and POP3 (Fig. 5a). POP3 was a japonica rice subgroup consisting of 32 rice germplasms. POP1 and POP2 were indica rice subgroups consisting of 263 and 186 rice germplasms, respectively. The F statistic (FST value) of the populations could strongly explain the genetic distance between populations. The average FST value for the three subgroups was 0.3501; the FST value of POP1 and POP3 was the largest (0.5482), while that of POP1 and POP2 was the smallest (0.0721). The results showed that the genetic distance between the japonica and indica rice subspecies was large, indicating that the core SNP markers were effective at discriminating the population structure of the germplasms.
POP1 was further divided into pop1, pop2, pop3 and pop-mix subgroups, which include 92, 94, 52 and 25 rice germplasms, respectively (Fig. 5b). POP2 was divided into 7 subgroups, pop1, pop2, pop3, pop4, pop5, pop6 and pop-mix, which consist of 8, 27, 26, 37, 3, 31 and 54 rice germplasms, respectively (Fig. 5c), and 4 subgroups were identified within POP3, pop1, pop2, pop3 and pop4, which include 2, 2, 23 and 6 rice germplasms, respectively (Fig. 5d). The average allele number per locus (ANP), the gene diversity index (GDI), and the PIC value of the POP1 population were 2.69, 0.19, and 0.16, respectively. The POP2 population exhibited high genetic diversity, with an ANP of 2.88, a GDI of 0.32 and a PIC of 0.27. For POP3, the ANP, GDI, and PIC were 2.53, 0.30, and 0.26, respectively (Table 5). These results revealed no significant correlation between the GDI and the number of materials in each subgroup, but there was a positive correlation between gene diversity and the PIC. The genetic diversity and PIC of each subgroup and corresponding group were essentially similar (Fig. 6). Based on the above results, we concluded that the core SNP markers have a superior ability to reflect the genetic diversity of different materials.
To utilize the benefits from the functional KASP markers used in our genotyping panel, molecular screening was carried out. Using grain quality properties as an example, the allelic types of three FM genes, GBSSI, SSIIa, and Badh2, were screened among the 481 rice germplasms. The results are shown in Fig. 7. In total, 385, 373, and 40 rice lines that harbor the favorable alleles of GBSSI (T allele), SSIIa (TT allele), and Badh2 (Del allele) were identified, respectively (Fig. 7a). Eighteen rice lines, including Xiangwanxian 13, Basmati 370, Ruanhua A, and PR 33319–9–1-1-5-3-5-4-1, harbor all three favorable alleles (Fig. 7b). These functional KASP markers of the core SNP array constitute a convenient and helpful method for excavating elite rice strains for breeding.
Utilization of the core SNP array to identify loci associated with milled grain traits via GWASs
In the core SNP array, 244 markers are related to important rice traits (yield, quality, biotic or abiotic stress, plant development and fertility, etc.). These markers provide important reference information for MAS breeding. To evaluate the validity of these trait-related markers, with milled grain properties as an example, a GWAS was conducted on 323 rice accessions via core SNP genotyping. We focused on the contribution of yield-related markers to grain traits and tried to identify new markers that affecting grain traits. Of the 244 markers, 18 were developed based on cloned genes related to grain shape or on reported GWAS-identified loci related to grain shape. Among these 18 markers, 9 were developed based on functional or polymorphic sites within the cloned genes GS3 and GW5, and the other 9 were developed based on highly reliable GWAS-identified loci. In this study, we paid special attention to validating whether these markers could be detected repeatedly.
The genotypes of 323 rice accessions were obtained via the core SNP array, and the kinship of the accessions was evaluated via SPAGeDi_1-2 g software. Most of the accessions had kinship values that were less than 0.1, while only 2.73% of the materials had kinship values greater than 0.3. The kinship values indicated that the population accessions had a relatively low genetic relatedness and that the population was suitable for GWASs. A certain degree of linkage disequilibrium (LD) exists between the locus combinations of the core markers. The regression equations governing the R2 parameters and the physical distance of the LD paired sites were analyzed by Tassel 5.0. The resulting equation y = 0.075ln(x) + 0.558 reflects the relationship between the R2 values and the LD. When an R2 value decreases to half of the maximum value, the attenuation distance is approximately 100 kb, which is consistent with results in previous studies (Fig. 8). Marker-trait associations for milled grain length (ML), milled grain thickness (MT), the LWR, and milled grain weight (MRW) were evaluated via the program TASSEL. A total of 31 KASP markers were significantly associated (P < 0.01) with ML and the LWR (Table 6). Eighteen of 31 markers were associated with more than two traits; moreover, one marker, SK05_27,742,506, was associated with four traits (ML, MT, LWR and MRW).
Among the 31 markers, 13 were developed based on cloned genes or on identified loci related to yield traits. The R2 value of the 13 markers contributing to their corresponding traits ranged from 0.0797 to 0.2688. SK05_27,742,506 is located within the cloned gene LTN1 sequence region and is significantly associated with four traits. The LTN1 gene encodes a protein containing a ubiquitin-binding domain and can regulate grain shape by affecting the absorption of Fe, K, Na, Ca and other metal elements. SK03_16,075,626 was significantly associated with ML, the LWR and MT, which is consistent with previous GWAS results in which this locus was significantly correlated with seed surface area. SK03_16,075,626 is located within the LOC_Os03g27990 sequence, which encodes the precursor of STRUBBELIG-RECEPTOR FAMILY 7, whose function is still unknown. SK05_5,396,755 was significantly associated with ML and the LWR and has been reported in previous GWAS results. This marker was located within the LOC_Os05g09550 sequence region, which encodes Der1-like family domain-containing proteins. SK05_5,537,852 and SK05_5,339,085 were developed based on cloned GW5 polymorphic loci. SK05_5,537,852 was significantly associated with ML and the LWR, while SK05_5,339,085 was significantly associated with MRW. SK03_16,733,441 is a FM of the GS3 gene and is significantly associated with ML in this study. SK03_872,082, which is located within LOC_Os03g02440 and encodes a WD repeat-containing protein 44, was developed in accordance with previous GWAS reports and was significantly associated with ML. SK06_27,438,624, SK06_27,481,339, SK06_27,498,819 and SK06_27,526,542 were all developed based on the cloned gene APO1, which affects grain traits by regulating the formation of rice vascular bundles. These four markers were significantly associated with the LWR; SK06_27,481,339 is located within the APO1 sequence interval. SK07_472,805 is located within the sequence of the cloned gene DEP, which encodes a transcription factor that consists of 267 amino acids, contains a MADS-box domain and plays an important role in the development of flower organs. SK08_21,582,840 is highly associated with ML and is located in COE1, which affects the growth of rice leaf veins and may indirectly affect grain development. Based on the above results, we detected cloned genes of GS3 and GW5, and the markers that were developed from the cloned genes related to grain shape or from reported GWAS loci related to grain shape were verified in the present study. Therefore, markers related to important rice traits within core SNP arrays can be used for allele screening to provide useful information to breeders.
Notably, several KASP markers were found to be associated with milled grain shape and brown planthopper resistance simultaneously. Three markers, SK11_23,607,373, SK03_15,001,183 and SK04_4,599,886, were closely linked with the green leafhopper resistance genes Grh2, Grh4 and Grh6(Fujita et al. 2010), respectively. Two other markers, SK06_647,869 and SK06_701,439, were closely linked with the brown planthopper resistance gene BPH25(t)(Fujita et al. 2010, Xiao et al. 2016). The discovery of these loci provides useful information for studying multiple effects of genes.
Necessity and significance of developing core KASP-SNP markers
Molecular MAS plays an important role in rice molecular breeding. The quantity and detection methods of molecular markers play a pivotal role in the MAS procedure. SNP markers, which are third-generation molecular markers, will effectively push the development of molecular breeding because of their widespread distribution across genomes and their applicability for automatic detection. KASP detection technology, which is based on both PCR and fluorescence detection, can meet the requirements of low-, medium- and high-throughput genotyping, including that involving both SNP and InDel markers, and provides a flexible, relatively inexpensive solution for mass SNP molecular marker transformation and utilization. Compared with Sanger and high-throughput sequencing, KASP technology is more efficient at identifying polymorphic loci. The genotyping results of KASP and Sanger sequencing for identical loci were also compared in this study, and no differences were observed. A comparison of the KASP method and the allele-specific PCR (AS-PCR) method in studies of wild rice mutants revealed the specificity and sensitivity of the KASP assay (Rosas et al. 2014).
In this study, 596 loci were identified from several SNP datasets and were used to develop KASP markers. After removing some invalid loci, such as those that failed to amplify and displayed no polymorphism, we ultimately obtained 467 valid KASP markers, which constituted a core SNP array. The SNP conversion rate includes two types of rates: the design success rate and the work success rate. The ratio of SNP sites that can be used to design primers to the total number of SNP sites is called the design success rate. The work success rate refers to the number of SNP sites that can generate genotype calls via primers to the number of SNP sites with successful designed primers (Semagn et al. 2014, Fan et al. 2003, Hyten et al. 2010). A KASP-SNP marker set was reported by the IRRI (Pariasca-Tanaka et al. 2015). This set of markers was transformed from 2015 SNP loci, and the success rate for the locus primer design was 100%, which was higher than that in this study (94.8%); the work success rate of the SNP markers was 86.3%, which was lower than that in this study (93.62%). Compared with that in the IRRI study, the proportion of polymorphic markers in this study is much greater: 37% versus 83.69%, respectively. These differences may be because the IRRI markers were verified only in two rice materials, while our markers were identified in a large number of rice materials (481 accessions). Therefore, the proportion of detection results and degree of polymorphism were higher in our study than in IRRI study. The conversion success rate reached 93.6% in the present study; this percentage is similar to the 93–94% conversion rate reported by LGC Genomics (LGC Genomics applications note, http://www.kbioscience.co.uk/reagents/ KASP_Taqmancomparison.pdf). For maize, KBioscience successfully designed assays for 1250 SNPs that corresponded to 1536 SNPs from an Illumina GoldenGate chip (81.4%) (Semagn et al. 2014).
Compared with the reported SNP marker set, the core SNP markers in this study were derived from multiple rice SNP databases, e.g., the Gramene database (http://ensembl.gramene.org/genome_browser/index.html), the Rice Diversity Project database (https://www.ricediversity.org/), the Rice Genome Annotation Project database (http://rice.plantbiology.msu.edu/), and the Rice SNP-Seek Database(http://snp-seek.irri.org), as well as reported genes or trait-related loci. Therefore, the core SNP array carries more genetic information and is more comprehensive than the SNP marker set. Among the eight groups of molecular markers in the core SNP array, two groups comprise cloned genes that are tightly linked or are target markers: one group is the FMs, and the other group consists of reliable SNP markers associated with traits reported in previous GWASs. These traits provide valuable information for MAS. In addition to these trait-related markers, in the present study, SNP markers that were related to quality control and indica-indica groupings and that were highly polymorphic were developed, which are valuable for analyzing the genetic background of materials.
Core SNP assays for rice germplasm assessment, genetic diversity and population evaluation
Genetic diversity acts as a reservoir for identifying superior alleles that control key agronomic and quality traits by allele mining (Nachimuthu et al. 2015). Assessment of genetic diversity and population structure in rice via different germplasm lines is often needed when developing core collections from national collections and international collections (Zhang et al. 2009, Zhang et al. 2011). Simple sequence repeat (SSR) markers are widely used in rice genetic diversity analyses because of their relatively large allelic variation, and SNP markers are also widely used in rice genetic diversity evaluation because of their easy automation. In this study, core SNP assays were also used for genetic diversity evaluation.
Based on the genotyping results of 467 core SNP markers, 481 rice germplasms were divided and categorized into three subgroups (two indica groups and one japonica group); this categorization seemed to differ from previously reported results in which only two groups, an indica group and a japonica group, were identified from collections (Zhang et al. 2009, Zhang et al. 2011). However, the FST value between the two indica subgroups was very low (0.0721). The average FST value between the two indica subgroups and the japonica subgroup was 0.489, which indicates that the indica population could be definitively distinguished from the japonica population; this value was similar to the FST value (0.517) of indica and japonica subspecies as determined via SNP markers (Muhamad et al. 2017). The genetic diversity and PIC of our population were 0.28 and 0.24, respectively. These results were similar to those of 215 rice germplasms, whose genetic diversity and PIC values were 0.26 and 0.24, respectively, and to those of 6984 rice varieties in northeastern India, whose genetic diversity and PIC values were 0.28 and 0.22, respectively, as determined via SSR markers (Xie et al. 2012, Choudhury et al. 2014). Based on the above results, we showed that the core SNP markers have a strong ability to reflect the genetic diversity of different materials.
To utilize the benefit from the functional KASP markers applied for our genotyping panel, molecular screening was carried out. Pariasca-Tanaka developed a KASP-SNP genotyping panel for detecting polymorphisms between different rice genera (Pariasca-Tanaka et al. 2015). KASP assays can also be used for genes that underpin key economic traits in crop breeding (Rasheed et al. 2016). For functional markers, KASP assays exhibit powerful detectability in breeding for disease resistance (Neelam et al. 2013). In our study, we used our developed core KASP assays to screen elite rice strains for superior quality. The genetic basis of rice in terms of eating and cooking quality is affected mainly by three physicochemical properties: AC, gel consistency (GC), and gelatinization temperature (GT); however, thus far, only the Waxy gene(ZY 1995) has been found to affect AC, and only the ALK gene (Gao et al. 2003, Gao et al. 2011) has been found to affect GT. Fragrance, which is controlled by BADH2 located on chromosome 8S(Chen et al. 2008), is another popular quality sought by consumers worldwide. To screen elite rice strains for eating and quality trait improvement, three KASP assays developed from the above three genes were used for large-scale genotyping. Eighteen rice lines were successfully screened for subsequent breeding. This system provides a convenient and helpful method for excavating elite rice strains in breeding. Therefore, KASP assays offer a cost-effective and scalable flexibility to applications that require small to large numbers of markers, such as quality control analysis, marker-assisted recurrent selection, and marker-assisted backcrossing.
The core SNP array provides a relevant method for excavating target traits
Candidate gene association mapping is used to detect functional SNPs or haplotypes associated with genes related agronomic traits so that identified germplasms carrying SNPs or haplotypes can be used for marker-assisted breeding(Huang and Brule-Babel 2012). In the core SNP array in the present study, 244 markers are related to important rice traits (yield, quality, biotic or abiotic stress, plant development and fertility). These markers provide important reference information for MAS-based breeding. To evaluate the validation of these trait-related markers, with milled grain properties as an example, a GWAS was conducted on 323 rice accessions via core SNP genotyping.
The marker SK05_5,396,755, which was significantly correlated with grain length and the LWR, was reported to be significantly correlated with grain width. The marker SK05_27,742,506 was significantly associated with grain length, the LWR and grain weight and was located within the cloned gene LTN1, which is a key functional gene related to yield (Hu et al. 2011). The markers SK05_5,537,852 and SK05_5,339,085, which were significantly correlated with grain length and the LWR, were reported to be within the sequence region of GW5, which is a functional gene responsible for grain width (Weng et al. 2008). SK06_27,481,339, SK06_27,438,624 and SK08_21,582,840, which were significantly correlated with milled rice length, were all located within the interval of the cloned yield-related gene; the corresponding cloned genes were APO1 and COE1, respectively (Ikeda et al. 2007, Kitagawa et al. 2010). The marker SK03_16,075,626 was strongly associated with grain length, grain thickness and the LWR, which was consistent with previous GWAS-identified loci that partly contributed to grain surface parameters (Yang et al. 2014). The cloned gene GS3 was identified via the FM SK03_16,733,441. The above results validated previous reports on grain traits, indicating the reliability and authenticity of the core SNP array. Furthermore, several KASP markers were found to be associated with milled grain shape and brown planthopper resistance simultaneously. Three markers, SK11_23,607,373, SK03_15,001,183 and SK04_4,599,886, were tightly linked to the green leafhopper resistance genes Grh2, Grh4 and Grh6 (Fujita et al. 2010), respectively. Two other markers, SK06_647,869 and SK06_701,439, were closely linked to the brown planthopper resistance gene BPH25(t)(Fujita et al. 2010, Xiao et al. 2016). The discovery of these loci provides useful information for studying multiple effects of genes. Marker-trait association analysis serves as a powerful tool for the dissection of complex agronomic traits and for the identification of alleles that can contribute to the enhancement of target traits (Yan et al. 2011). Therefore, core SNP markers related to important rice traits can be used for allele screening to provide useful information to breeders.
In this study, we developed an efficient and versatile core SNP assays based on 467 KASP markers and successfully used them for rice germplasm assessment, genetic diversity and population evaluation. The core KASP arrays were also used for association analysis with milled grain traits. The results showed that this core SNP assays were effective and reliable, and will be valuable for promoting SNP molecular breeding in rice.
A total of 530 rice accessions from various regions worldwide, including rice lines from the Germplasm Bank of South China Agricultural University, male-sterile lines, advanced breeding lines, and hybrid combinations, were used in this study (Additional file 2: Table S2). All accessions and lines were planted in the field in Guangzhou (a traditional flatland field), Guangdong Province, China, during the dry season (DS) in 2015 and during the wet season (WS) in 2016.
Collection of SNPs
Several SNP datasets were used, including the Rice Diversity Project SNP dataset (http://www.ricediversity.org/), a high polymorphism information content (PIC) SNP dataset (Chen et al. 2011), a GWAS SNP dataset (Zhao et al. 2011), the SNP array from Affymetrix Rice 44 K SNP microarray (Kurokawa et al. 2016), the Rice Annotation Project Database (http://rapdb.dna.affrc.go.jp), the SNP array (Yonemaru et al. 2014) and the “OsSNPnks” 50 K SNP chip (Singh et al. 2015). Eight kinds of SNP data were chosen for developing KASP markers distributed throughout the genome (Table 1). Sixty-one SNPs of RiceOPA1.0 in subset 1 were used for quality control and for assigning accessions to subgroups (Additional file 3: Table S3). Considering the higher frequency of usage of indica rice, 64 SNPs from RiceOPA2.1 in subset 2, which were supposed to be effectively polymorphic between indica/indica populations, were specifically chosen (Additional file 4: Table S4). Fifty-three SNPs with a relatively high PIC from a set of breeder-friendly SNP markers were also added as subset 3 of our genotyping panel (Additional file 5: Table S5). Functional nucleotide polymorphism (FNP) has been useful for selection in rice breeding, and 21 thoroughly studied FNP markers were selected; these markers composed subset 4 (Additional file 6: Table S6). Subset 5 (Additional file 7: Table S7) and subset 6 (Additional file 8: Table S8) comprised reported key SNP-targeted genes or overlapping gene intervals, which were designed for gene tracking. SNPs associated with important traits such as flowering time, blast resistance, amylose content (AC), and protein content revealed by GWAS via cross-population-based mapping were introduced as subset 7 (Additional file 9: Table S9). The trait-associated SNPs were selected based on their correlation degree with the agronomic traits. Only SNPs offering great contribution to phenotypic variance with significant P values were included in subset 7. Based on the SNP distribution, randomly selected markers for large gaps in the chromosomes were supplemented for gap filling in subset 8 (Additional file 10: Table S10). A total of 596 SNP sites were chosen for primer design and genotyping.
Genomic DNA extraction and SNP genotyping
The rice genomic DNA was extracted using the cetyl-trimethylammonium bromide (CTAB) method and quantified using a NanoDrop ND-1000 spectrophotometer (Thermo Scientific, Wilmington, USA). To increase the efficiency and reduce the genotyping costs, high-throughput DNA extraction method (Chen et al. 2016) was applied for rapid DNA extraction of batch samples. The selected SNPs were sent to LGC Limited, UK, for primer design. For these SNPs, we extracted 250 bp surrounding the candidate SNP on either side and ordered KASP primer oligos from LGC. The genotyping assays were tested in a 96-well format and established as 10 μL reactions (4.85 μL of template DNA (50–75 ng), 5.0 μL of 2× Kaspar mix, and 0.15 μL of primer mix). PCR was performed on a StepOne Plus machine in accordance with the following protocol: preread stage at 30 °C for 1 min, hot start at 95 °C for 15 min, 10 touchdown cycles (95 °C for 20 s; touchdown at 65 °C, − 1 °C per cycle, 25 s) and then 26 cycles of amplification (95 °C for 10 s; 57 °C for 60 s).
Fluorescent data were collected during the preread and postread stages (30 °C for 1 min). For most of breeders in labs, 96-SNP array is the most commonly used because it is more economic, operable and use-friendly for various-sample-size genotyping. Actually KASP assays can also be manipulated on 384-plate format. The 384-plate format PCR system can be established as 5 μL reactions (2.5 μL of template DNA (25 ng), 2.5 μL of 2× Kaspar mix, and 0.07 μL of primer mix). The genotyping efficiency can be more greatly upgraded with the 384-plate format and the genotyping cost can be reduced at the same time due to less reagent usage per assay. The breeders can adjust the genotyping system according to specific needs and laboratory equipment conditions. Once the run was completed, analysis was carried out with StepOne Software V2. The primers of all the KASP arrays used in our study can be viewed in Additional file 11: Table S11.
Statistical analyses and marker-trait association studies
The SNP allele frequency and PIC were estimated for each locus using PowerMarker V3.25(Liu and Muse 2005). In addition, genetic distances between genotypes and neighbor-joining (NJ) tree distances were calculated using Power Marker 3.5. Genetic similarity coefficients between each variety were calculated using NTSYS-pc 2.10. A similarity matrix was used to construct a dendrogram via the unweighted pair-group method arithmetic average (UPGMA) algorithm and nested clustering (SHAN) routine to determine the genetic relationships among the materials. The UPGMA trees were visualized with MEGA 5(Tamura et al. 2011). The number of alleles per locus, the diversity index, and the PIC were subsequently estimated. The population structure was estimated with the program Structure V2.3.2 (Falush et al. 2003). The hypotheses for 2–10 subpopulations (K) with an admixture model and correlated allelic frequencies were tested; the length of the burn-in period was equal to 10,000 iterations, and 100,000 Markov Chain Monte Carlo replications were performed after the burn-in period. Ten runs of the Structure program were performed, and an average likelihood value, LnP(D), across all runs was calculated for each K. The most likely number of clusters (K) was selected by comparing the logarithmized probabilities of the LnP(D) and ΔK data.
The milled rice shape parameters of 323 out of 481 germplasms were investigated. Images of the more than 100 milled rice grains were captured via a CanoScan 5600F scanner (Canon, Japan) and the supplied software; the images were not enhanced. The length, width, length/width ratio (LWR), thickness, and 100 milled rice weight were measured precisely using SmartGrain software (Tanabata et al. 2012). An association study between marker alleles and the above trait data was performed with TASSEL 5.0 software, taking into account gross level population structure (Q) (Bradbury et al. 2007). The P value (marker) determining whether a marker is associated with a trait and the R2 value (marker) indicating the fraction of the total variation explained by the marker were reported.
Alexandrov N, Tai S, Wang W, Mansueto L, Palis K, Fuentes RR, Ulat VJ, Chebotarov D, Zhang G, Li Z, Mauleon R, Hamilton RS, McNally KL (2015) SNP-seek database of SNPs derived from 3000 rice genomes. Nucleic Acids Res 43(Database issue):D1023–D1027
Bradbury PJ, Zhang Z, Kroon DE, Casstevens TM, Ramdoss Y, Buckler ES (2007) TASSEL: software for association mapping of complex traits in diverse samples. Bioinformatics. 23(19):2633–2635
Chen HD, He H, Zou YJ, Chen W, Yu RB, Liu X, Yang Y, Gao YM, Xu JL, Fan LM, Li Y, Li ZK, Deng XW (2011) Development and application of a set of breeder-friendly SNP markers for genetic analyses and molecular breeding of rice (Oryza sativa L.). Theor Appl Genet 123(6):869–879
Chen LK, Gao WW, Guo T, Huang CH, Huang M, Wang JF, Xiao WM, Yang GL, Liu YZ, Wang H, Chen ZQ (2016) A genotyping platform assembled with high-throughput DNA extraction, codominant functional markers, and automated CE system to accelerate marker-assisted improvement of rice. Mol Breed 36(9):123
Chen M, Zhao Z, Chen L, Zhou F, Zhong Z, Jiang L and Wan J (2013) Genetic analysis and fine mapping of a semi-dwarf gene in a centromeric region in rice (Oryza sativa L.). Breed Sci. 63(2): 164–168.
Chen SH, Yang Y, Shi WW, Ji Q, He F, Zhang ZD, Cheng ZK, Liu XN and Xu ML (2008) Badh2, encoding betaine aldehyde dehydrogenase, inhibits the biosynthesis of 2-acetyl-1-pyrroline, a major component in rice fragrance. Plant Cell 20(7): 1850–1861.
Chen T, Zhang Y, Zhao L, Zhu Z, Lin J, Zhang S, Wang C (2009) A cleaved amplified polymorphic sequence marker to detect variation in Wx locus conditioning translucent endosperm in Rice. Rice Sci 16(2):106–110
Chen W, Gao YQ, Xie WB, Gong L, Lu K, Wang WS, Li Y, Liu XQ, Zhang HY, Dong HX, Zhang W, Zhang LJ, Yu SB, Wang GW, Lian XM, Luo J (2014) Genome-wide association analyses provide genetic and biochemical insights into natural variation in rice metabolism. Nat Genet 46(7):714–721
Choudhury DR, Singh N, Singh AK, Kumar S, Srinivasan K, Tyagi RK, Ahmad A, Singh NK, Singh R (2014) Analysis of genetic diversity and population structure of Rice germplasm from north-eastern region of India and development of a Core germplasm set. PLoS One 9(11)
Falush D, Stephens M and Pritchard JK (2003) Inference of population structure using multilocus genotype data: Linked loci and correlated allele frequencies. Genet. 164(4):1567–587.
Fan JB, Oliphant A, Shen R, Kermani BG, Garcia F, Gunderson KL, Hansen M, Steemers F, Butler SL, Deloukas P, Galver L, Hunt S, McBride C, Bibikova M, Rubano T, Chen J, Wickham E, Doucet D, Chang W, Campbell D, Zhang B, Kruglyak S, Bentley D, Haas J, Rigault P, Zhou L, Stuelpnagel J, Chee MS (2003) Highly parallel SNP genotyping. Cold Spring Harb Symp Quant Biol 68:69–78
Fan CH, Xing YZ, Mao HL, Lu TT, Han B, Xu CG, Li XH and Zhang QF (2006) GS3, a major QTL for grain length and weight and minor QTL for grain width and thickness in rice, encodes a putative transmembrane protein. Theorl Appl Genet. 112(6):1164–171
Feltus FA, Wan J, Schulze SR, Estill JC, Jiang N, Paterson AH (2004) An SNP resource for rice genetics and breeding based on subspecies indica and japonica genome alignments. Genome Res 14(9):1812–1819
Fujita D, Yoshimura A, Yasui H (2010) Development of near-isogenic lines and pyramided lines carrying resistance genes to green rice leafhopper (Nephotettix cincticeps Uhler) with the Taichung 65 genetic background in rice (Oryza sativa L.). Breed Sci 60(1):18–27
Gao Z, Zeng D, Cui X, Zhou Y, Yan M, Huang D, Li J, Qian Q (2003) Map-based cloning of the ALK gene, which controls the gelatinization temperature of rice. Sci China C Life Sci 46:661–668
Gao ZY, Zeng DL, Cheng FM, Tian ZX, Guo LB, Su Y, Yan MX, Jiang H, Dong GJ, Huang YC, Han B, Li JY, Qian Q (2011) ALK, the key gene for gelatinization temperature, is a modifier gene for gel consistency in Rice. J Integr Plant Biol 53(9):756–765
Hu B, Zhu C, Li F, Tang J, Wang Y, Lin A, Liu L, Che R, Chu C (2011) LEAF TIP NECROSIS1 plays a pivotal role in the regulation of multiple phosphate starvation responses in rice. Plant Physiol 156(3):1101–1115
Huang XQ, Brule-Babel A (2012) Sequence diversity, haplotype analysis, association mapping and functional marker development in the waxy and starch synthase IIa genes for grain-yield-related traits in hexaploid wheat (Triticum aestivum L.). Mol Breed 30(2):627–645
Hyten DL, Cannon SB, Song QJ, Weeks N, Fickus EW, Shoemaker RC, Specht JE, Farmer AD, May GD, Cregan PB (2010) High-throughput SNP discovery through deep resequencing of a reduced representation library to anchor and orient scaffolds in the soybean whole genome sequence. BMC Genomics 11
Ikeda K, Ito M, Nagasawa N, Kyozuka J, Nagato Y (2007) Rice ABERRANT PANICLE ORGANIZATION 1 (APO1), encoding an F-box protein, regulates meristem fate. The Plant J 51(6):1030–1040
Jiang N, Li Z, Wu J, Wang Y, Wu L, Wang S, Wang D, Wen T, Liang Y, Sun P, Liu J, Dai L, Wang Z, Wang C, Luo M, Liu X, Wang GL (2012a) Molecular mapping of the Pi2/9 allelic gene Pi2-2 conferring broad-spectrum resistance to Magnaporthe oryzae in the rice cultivar Jefferson. Rice (N Y) 5(1):29
Jiang S, Zhang X, Zhang F, Xu Z, Chen W, Li Y (2012b) Identification and fine mapping of qCTH4, a quantitative trait loci controlling the chlorophyll content from tillering to heading in rice (Oryza sativa L.). J Hered 103(5):720–726
Kitagawa K, Kurinami S, Oki K, Abe Y, Ando T, Kono I, Yano M, Kitano H, Iwasaki Y (2010) A novel kinesin 13 protein regulating Rice seed length. Plant Cell Physiol 51(8):1315–1329
Kurokawa Y, Noda T, Yamagata Y, Angeles-Shim R, Sunohara H, Uehara K, Furuta T, Nagai K, Jena KK, Yasui H, Yoshimura A, Ashikari M, Doi K (2016) Construction of a versatile SNP array for pyramiding useful genes of rice. Plant Sci 242:131–139
Liu KJ, Muse SV (2005) PowerMarker: an integrated analysis environment for genetic marker analysis. Bioinformatics. 21(9):2128–2129
McNally KL, Childs KL, Bohnert R, Davidson RM, Zhao K, Ulat VJ, Zeller G, Clark RM, Hoen DR, Bureau TE, Stokowski R, Ballinger DG, Frazer KA, Cox DR, Padhukasahasram B, Bustamante CD, Weigel D, Mackill DJ, Bruskiewich RM, Ratsch G, Buell CR, Leung H, Leach JE (2009) Genomewide SNP variation reveals relationships among landraces and modern varieties of rice. Proc Natl Acad Sci U S A 106(30):12273–12278
Muhamad K, Ebana K, Fukuoka S, Okuno K (2017) Genetic relationships among improved varieties of rice (Oryza sativa L.) in Indonesia over the last 60 years as revealed by morphological traits and DNA markers. Genet Resour Crop Evol 64(4):701–715
Nachimuthu VV, Muthurajan R, Duraialaguraja S, Sivakami R, Pandian BA, Ponniah G, Gunasekaran K, Swaminathan M, Suji KK, Sabariappan R (2015) Analysis of population structure and genetic diversity in Rice germplasm using SSR markers: an initiative towards association mapping of agronomic traits in Oryza Sativa. Rice. 8
Neelam K, Brown-Guedira G, Huang L (2013) Development and validation of a breeder-friendly KASPar marker for wheat leaf rust resistance locus Lr21. Mol Breed 31(1):233–237
Pariasca-Tanaka J, Lorieux M, He C, McCouch S, Thomson MJ, Wissuwa M (2015) Development of a SNP genotyping panel for detecting polymorphisms in Oryza glaberrima/O. Sativa interspecific crosses. Euphytica. 201(1):67–78
Rasheed A, Wen W, Gao F, Zhai S, Jin H, Liu J, Guo Q, Zhang Y, Dreisigacker S, Xia X, He Z (2016) Development and validation of KASP assays for genes underpinning key economic traits in bread wheat. Theor Appl Genet 129(10):1843–1860
Rosas JE, Bonnecarrere V and de Vida FP (2014) One-step, codominant detection of imidazolinone resistance mutations in weedy rice (Oryza sativa L.). Electron J Biotechnol. 17(2) :95–101.
Semagn K, Babu R, Hearne S, Olsen M (2014) Single nucleotide polymorphism genotyping using Kompetitive allele specific PCR (KASP): overview of the technology and its application in crop improvement. Mol Breed 33(1):1–14
Singh N, Jayaswal PK, Panda K, Mandal P, Kumar V, Singh B, Mishra S, Singh Y, Singh R, Rai V, Gupta A, Sharma TR, Singh NK (2015) Single-copy gene based 50 K SNP chip for genetic studies and molecular breeding in rice. Scientific reports. 5 Tamura K, Peterson D, Peterson N, Stecher G, Nei M and Kumar S (2011) MEGA5: molecular evolutionary genetics analysis using maximum likelihood, evolutionary distance, and maximum parsimony methods. Mol Biol Evol 28(10):2731–2739
Tanabata T, Shibaya T, Hori K, Ebana K, Yano M (2012) SmartGrain: high-throughput phenotyping software for measuring seed shape through image analysis. Plant Physiol 160(4):1871–1880
Tian ZX, Yan CJ, Qian QA, Yan S, Xie HL, Wang F, Xu JF, Liu GF, Wang YH, Liu QQ, Tang SZ, Li JY, Gu MH (2010) Development of gene-tagged molecular markers for starch synthesis-related genes in rice. Chin Sci Bull 55(33):3768–3777
Tripathi R, Kumar K, Balachandar R, Marimuthu P, Varghese M, Bharath S (2016) Cognitive markers of mild cognitive impairment: an Indian experience. Ann Indian Acad Neurol 19(1):164
Weng J, Gu S, Wan X, Gao H, Guo T, Su N, Lei C, Zhang X, Cheng Z, Guo X, Wang J, Jiang L, Zhai H, Wan J (2008) Isolation and initial characterization of GW5, a major QTL associated with rice grain width and weight. Cell Res 18(12):1199–1209
Xiao C, Hu J, Ao YT, Cheng MX, Gao GJ, Zhang QL, He GC, He YQ (2016) Development and evaluation of near-isogenic lines for brown planthopper resistance in rice cv. 9311. Sci Rep 6
Xie FM, Guo LB, Ren GJ, Hu PS, Wang F, Xu JL, Li XQ, Qiu FL, dela Paz MA (2012) Genetic diversity and structure of indica rice varieties from two heterotic pools of southern China and IRRI. Plant Genetic Resources-Characterization and Utilization 10(3):186–193
Yan JB, Warburton M, Crouch J (2011) Association mapping for enhancing maize (Zea mays L.) genetic improvement. Crop Sci 51(2):433–449
Yang Y, Rao Y, Xu J, Shao G, Leng Y, Huang L, Wang L, Dai L, Zhang G, Hu J, Zhu L, Li C, Gao Z, Guo L, Qian Q, Zeng D (2014) Genetic analysis of sugar-related traits in rice grain. S Afr J Bot 93:137–141
Yonemaru J, Mizobuchi R, Kato H, Yamamoto T, Yamamoto E, Matsubara K, Hirabayashi H, Takeuchi Y, Tsunematsu H, Ishii T, Ohta H, Maeda H, Ebana K, Yano M (2014) Genomic regions involved in yield potential detected by genome-wide association analysis in Japanese high-yielding rice cultivars. BMC Genomics 15:346
Zhang D, Zhang H, Wang M, Sun J, Qi Y, Wang F, Wei X, Han L, Wang X, Li Z (2009) Genetic structure and differentiation of Oryza sativa L. in China revealed by microsatellites. Theor Appl Genet 119(6):1105–1117
Zhang P, Li J, Li X, Liu X, Zhao X, Lu Y (2011) Population structure and genetic diversity in a rice core collection (Oryza sativa L.) investigated with SSR markers. PLoS One 6(12):e27565
Zhao K, Tung CW, Eizenga GC, Wright MH, Ali ML, Price AH, Norton GJ, Islam MR, Reynolds A, Mezey J, McClung AM, Bustamante CD, McCouch SR (2011) Genome-wide association mapping reveals a rich genetic architecture of complex traits in Oryza sativa. Nat Commun 2
ZY W (1995) The amylose content in rice endosperm is related to the post-transcriptional regulation of the waxy gene. Plant J 7:613–622
We also thank Lixin Luo and Jing Yang for their suggestions and help for experiments and data analyses.
Financial support for this research was provided in part by a grant from the National Key Technology Research and Development Program of China (No. 2016YFD0102102), the Science and Technology Project of Guangdong Province (No. 2015B020231011), National Key Research and Development Project (2016YFD0101100) and the earmarked fund for Modern Agro-Industry Technology Research System (No. CARS-01-12).
Availability of data and materials
All data generated or analysed during this study are included in this published article and its supplementary information files.
Ethics approval and consent to participate
Consent for publication
The authors declare that they have no competing interests.
Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.
Table S1. Primers for sequencing and genotyping. (XLSX 10 kb)
Table S2. List of the rice germplasm used in this study. (XLSX 39 kb)
Table S5. Subset 3 of SNPs. (XLSX 12 kb)
Table S6. Subset 4 of SNPs. (XLSX 11 kb)
Table S7. Subset 5 of SNPs. (XLSX 14 kb)
Table S8. Subset 6 of SNPs. (XLSX 25 kb)
Table S9. Subset 7 of SNPs. (XLSX 12 kb)
Table S11. KASP assay primers used in the study. (XLSX 39 kb)
