OsProT1 and OsProT3 Function to Mediate Proline- and γ-aminobutyric acid-specific Transport in Yeast and are Differentially Expressed in Rice (Oryza sativa L.)

Article metrics

  • 398 Accesses



Proline (Pro) and γ-aminobutyric acid (GABA) play important roles in plant development and stress tolerance. However, the molecular components responsible for the transport of these molecules in rice remain largely unknown.


Here we identified OsProT1 and OsProT3 as functional transporters for Pro and GABA. Transient expression of eGFP-OsProTs in plant protoplasts revealed that both OsProT1 and OsProT3 are localized to the plasma membrane. Ectopic expression in a yeast mutant demonstrated that both OsProT1 and OsProT3 specifically mediate transport of Pro and GABA with affinity for Pro in the low affinity range. qRT-PCR analyses suggested that OsProT1 was preferentially expressed in leaf sheathes during vegetative growth, while OsProT3 exhibited relatively high expression levels in several tissues, including nodes, panicles and roots. Interestingly, both OsProT1 and OsProT3 were induced by cadmium stress in rice shoots.


Our results suggested that plasma membrane-localized OsProT1 and OsProT3 efficiently transport Pro and GABA when ectopically expressed in yeast and appear to be involved in various physiological processes, including adaption to cadmium stress in rice plants.


Pro and GABA are key players in plant growth and resistance to stresses. Accumulation of Pro in pollen is crucial for pollen fertility and deficiency of Pro leads to morphological defects in leaves and inflorescences in Arabidopsis (Funck et al. 2012; Mattioli et al. 2012; Biancucci et al. 2015; Mattioli et al. 2018). In maize plants, Pro was also observed to contribute to final grain production (Spoljarevic et al. 2011). Moreover, Pro is proven to be a member of major compatible solutes which are highly soluble compounds with low molecular weight and are usually nontoxic even at high concentrations (Ashraf and Foolad 2007). It could provide osmotic effects for plants to cope with stresses including drought, salt, nutrient deficiency, heat, heavy metal toxicity and UV-B radiation (Szabados and Savoure 2010; Per et al. 2017). During stress, Pro content is dramatically elevated by enhanced synthesis and decreased degradation (Szabados and Savoure 2010; Kaur and Asthir 2015). Increased Pro synthesis is mainly attributed to upregulation of P5CS which is a key enzyme for Pro biosynthesis; thus enhancing P5CS expression by transgenic approach could effectively improve the ability of plant to tolerate stresses (Kishor et al. 1995; Igarashi et al. 2000).

GABA, a nonproteinogenic amino acid, rapidly accumulates in response to both abiotic and biotic stresses (Shelp et al. 2012; Bown and Shelp 2016). It has been shown that GABA functions in defense against insect herbivory and drought tolerance in Arabidopsis (Scholz et al. 2015; Bown and Shelp 2016; Mekonnen et al. 2016). Moreover, GABA can bind Aluminum-Activated Malate Transporter (ALMT) membrane channels and stimulate anion efflux or inhibit anion influx at the tonoplast or plasma membrane during drought-induced stomatal closure (Ramesh et al. 2015; Bown and Shelp 2016). In addition, GABA is considered as a pivotal amino acid in post-pollination fertilization (Biancucci et al. 2015).

The transport processes of Pro were considered to be important for altering Pro content inside plants, as no relation was observed between the accumulation and synthesis of Pro during grapevine berry maturation (Stines et al. 1999). Biosynthesis of Pro occurs mainly in the cytosol and chloroplasts (Szabados and Savoure 2010), but Pro can be detected in the xylem and phloem sap in several plant species (Weibull et al. 1990; Bialczyk et al. 2004; Lehmann et al. 2010), further confirming the cross-membrane and cross-tissue transport of Pro. Moreover, the long-distance transport of Pro in phloem is increased in response to water stress in alfalfa (Girousse et al. 1996), indicating that Pro transport is essential for plants under both normal and stress conditions. Similar observations were also obtained for GABA, as it can be released from mesophyll cells (Chung et al. 1992) and transported through vascular tissues (Shelp et al. 1999).

The transporters responsible for Pro transport have been identified in some subfamilies of the amino acid transporter (AAT) family in Arabidopsis including the amino acid permease (AAP) family, the lysine-histidine transporter family and the Pro transporter (ProT) family. Meanwhile, some members of the ProT family and GABA transporters in Arabidopsis are also responsible for transporting GABA (Lehmann et al. 2010; Shelp et al. 2012). It is worth mentioning that ProTs frequently display specific transport activity for Pro, glycine betaine and GABA in different species including Arabidopsis, tomato, barley and the common bean (Schwacke et al. 1999; Grallath et al. 2005; Fujiwara et al. 2010; Lehmann et al. 2011; Chen et al. 2016).

Previous studies have identified 79 and 85 AAT genes in rice genomes (Lu et al. 2012; Zhao et al. 2012). However, the transport activities of the encoded proteins have rarely been examined. As such, the components responsible for Pro and GABA transport in rice remain unclear. As OsProTs are likely to participate in these transport processes and OsProT2 has been characterized as a functional Pro transporter through its expression in Xenopus oocytes (Igarashi et al. 2000), we identified and functionally characterized the other two OsProT members in order to uncover the details for Pro and GABA transport in rice. Our results demonstrated that plasma membrane-localized OsProT1 and OsProT3 are functional uptake transporters for Pro and GABA in yeast and might get involved in normal growth and stress tolerance in planta.


Phylogenetic Analysis and Prediction of Transmembrane Helices for OsProT1 and OsProT3

The ProT subfamily contains three members in rice (Zhao et al. 2012). The OsProT1 sequence exhibits 38.7% and 40% identity to OsProT2 and OsProT3 (Additional file 1: Figure S1), respectively. Surprisingly, a relatively higher identity of 81.4% was found between OsProT2 and OsProT3 (Additional file 1: Figure S1), indicating that OsProT2 and OsProT3 might have similar molecular functions. Phylogenetic analysis of ProTs in Oryza sativa, Zea mays, Sorghum bicolor, Arabidopsis thaliana, Lycopersicon esculentum, Brachypodium distachyon, Vitis vinifera, Glycine max and Gossypium hirsutum was performed to examine the evolutionary relationships of OsProTs with other ProTs. OsProT1 are closely related with ZmProT1 and SbProT1, while OsProT2 and OsProT3 show closer evolutionary relationship to XP 003561540.1 from Brachypodium distachyon than ProTs from other species (Fig. 1a). Additionally, ProT members from Arabidopsis thaliana, Lycopersicon esculentum and Gossypium hirsutum which all belong to dicotyledons can be grouped into three small clusters, and each of these three clusters is specific to one species (Fig. 1a). Noting that only one ProT member existed in Vitis vinifera which has not undergone recent whole genome duplication (Jaillon et al. 2007).

Fig. 1

Phylogenetic analysis and prediction of transmembrane helices for OsProT1 and OsProT3. a Phylogenetic analysis of ProT protein sequences from Oryza sativa (Os), Zea mays (Zm), Sorghum bicolor (Sb), Arabidopsis thaliana (At), Lycopersicon esculentum (Le), Brachypodium distachyon, Vitis vinifera, Glycine max and Gossypium hirsutum. Dendrogram was generated by ( with 1000 bootstrap replications using the default parameters. Values at each tree root indicate bootstrap values and values on each branch indicate branch lengths. b Transmembrane prediction of OsProT1 and ProT3 using Phobius (

Membrane-spanning regions analyses using Phobius ( revealed that both OsProT1 and OsProT3 were predicted to contain 11 putative transmembrane regions (Fig. 1b). The regions between 9th and 10th transmembrane segments of OsProT1 and OsProT3 are slightly short.

OsProT1 and OsProT3 are Localized in the Plasma Membrane

Prediction of membrane-spanning regions of OsProT1 and OsProT3 indicated that these two proteins are both localized to membranes. To confirm whether OsProT1 and OsProT3 are targeted to the plasma membrane or to subcellular membranes, eGFP fusion proteins driven by the 35S promoter were transiently expressed in mesophyll protoplasts of Arabidopsis. As shown in Fig. 2, GFP fluorescence of eGFP-OsProT1 or eGFP-OsProT3 was observed at the plasma membrane and co-localizes with the plasma membrane marker Dil (1,1′-dioctadecyl-3,3,3′,3′-tetramethylindocarbocyanine perchlorate). These data demonstrate that OsProT1 and OsProT3 are localized to the plasma membrane.

Fig. 2

Subcellular localization of eGFP-OsProT fusion proteins in Arabidopsis mesophyll protoplasts. eGFP-OsProT1 or eGFP-OsProT3 was driven by the 35S promoter and transiently expressed in Arabidopsis protoplasts. The fluorescent dye Dil at a concentration of 10 μM was used to indicate the plasma membrane. Bars = 10 μm

OsProT1 and OsProT3 are Functional Transporters for pro and GABA in Yeast

To investigate the transport activities of OsProT1 and OsProT3, functional complementation experiments were performed using the yeast amino acid transport mutant 2210α. The 2210α yeast strain lacks ten amino acid transporters addressed at the plasma membrane and is unable to grow on any proteinogenic amino acid or GABA as the sole nitrogen source, except for arginine (Besnard et al. 2016). OsProT1 and OsProT3 were expressed in 2210α yeast under the control of the GPD promoter; transformants expressing OsProT1 or OsProT3 were able to grow on media with Pro or GABA as the sole nitrogen resource (Fig. 3a and b), suggesting of that OsProT1 and OsProT3 have the ability to uptake Pro or GABA into yeast cells. Interestingly, 2210α expressing OsProT1 or OsProT3 failed to restore the growth defect on media with other amino acids as the sole nitrogen resource, including acidic (Asp or Glu), aromatic (Phe, Trp, or Asn), or other neutral (Val, Thr, Ser, Leu, Ile, Gly, or Ala) amino acids (Fig. 3c). These results suggested that OsProT1 and OsProT3 are functional transporters and specifically transport Pro and GABA.

Fig. 3

Functional analyses of OsProT1 and OsProT3 in yeast mutant 2210α. a-c, Yeast mutant strain 2210α was transformed with p426GPD empty vector (EV) or the plasmid containing the coding sequence of OsProT1 or OsProT3, and grown on SD plates with (NH4)2SO4, Pro, GABA or other amino acid as the sole nitrogen source for about 4 days

The functions of OsProT1 and OsProT3 in the uptake of Pro were further confirmed by 15N-Pro labeled experiments. Yeast 2210α cells expressing OsProT1, OsProT3 or the empty vector (EV) were cultured with 15N labeled Pro, and the 15N content in yeast cells was subsequently analyzed. As shown in Fig. 4, 2210α cells expressing OsProT3 possessed significantly higher 15N content than the cells expressing OsProT1, and both were higher than that in cells transformed with EV 15 min or 30 min after labeling (Fig. 4), indicating that both OsProT1 and OsProT3 are Pro transporters for absorbing Pro into cells and that OsProT3 is more capable than OsProT1 in transporting Pro when expressed in yeast.

Fig. 4

Uptake of 15N-labeled Pro by yeast 2210α cells. Yeast cells expressing OsProT1 or OsProT3 were incubated with 1.5 mM 15N-Pro for 15 min and 30 min, and the 15N retained in the cells was subsequently measured. Values are means ± SD, n = 4

To determine the affinity of OsProT1 and OsProT3 for Pro, concentration-dependent 15N labeled Pro uptake by 2210α expressing OsProT1 and OsProT3 were performed. Apparent Km (Kmapp) values were determined by fitting 15N uptake rates at each substrate concentration to the Michaelis-Menten equation. As shown in Fig. 5, Kmapp values of OsProT1 and OsProT3 for Pro are 4.24 ± 1.24 mM and 1.81 ± 0.23 mM, respectively. These data indicated that OsProT1 and OsProT3 are both in the low-affinity range for transport of Pro, while OsProT3 showed a higher affinity than OsProT1 with respect to Pro transport.

Fig. 5

OsProT1 and OsProT3 are low affinity Pro transporters. a and b, OsProT1 (a) or OsProT3 (b) expressed yeast strain 2210α was cultivated with different concentrations of 15N-labeled Pro for 10 min and the 15N content was subsequently determined after being collected and dried. Kmapp values were calculated by fitting to the Michaelis-Menten equation in the SigmaPlot 12.0 program. Data are means ± SD, n = 4

OsProT1 and OsProT3 showed Differential Expression Patterns in Rice

To evaluate the physiological function of OsProT1 and OsProT3, their expression levels in different tissues at vegetative and reproductive stages were detected. OsProT1 exhibited highest expression in the leaf sheath at the vegetative stage with higher expression in nodes at the reproductive stage than in other tissues (Fig. 6a). OsProT3 showed relatively high expression levels in several tissues including root and leaf blade with higher levels in nodes and peduncles (Fig. 6b). OsProT2 was predominantly expressed in the leaf blade, especially in the flag leaf blade at the reproductive stage (Additional sfile 1: Figure S2). These data indicated that OsProT members are expressed differentially within rice plant and might be involved in different transport processes for Pro and GABA.

Fig. 6

Expression levels of OsProT1 and OsProT3 in different organs at vegetative and reproductive stages. a and b, Different samples were collected from rice grown in the soil. The expression levels of OsProT1 (a) and OsProT3 (b) were determined by real-time RT-PCR using the OsACTIN1 gene as internal control. Values are means ± SD, n = 4

Given that abiotic stresses affect the expression of ProT genes in many species, including Arabidopsis, common bean and barley (Rentsch et al. 1996; Ueda et al. 2001; Lehmann et al. 2010; Chen et al. 2016), we further characterized the expression levels of OsProTs in response to diverse abiotic stresses. Nitrogen deficiency or high nitrogen treatment exerted only a weak influence on OsProTs expressions, except for OsProT2, which was significantly repressed in roots by nitrogen deficiency (Fig. 7a-d, Additional file 1: Figure S3a and b). The expressions of OsProT1 and OsProT3 in shoots, but not in roots, were significantly enhanced by cadmium treatment (Fig. 7e and f). However, cadmium stress exerted very weak effects on OsProT2 expression (Additional file 1: Figure S3c and d), and salt stress hardly affects the expression of all OsProTs in both the shoots and roots (Fig. 7e-h, Additional file 1: Figure S3c and d). These data suggested that transcript regulation of OsProTs might be involved in coping with nutrient and heavy metal stress in rice plants.

Fig. 7

Expression levels of OsProTs in response to different abiotic stresses. a-dOsProT1 (a, c) and OsProT3 (b, d)  transcript levels in response to nitrogen deficiency or high nitrogen treatment. e-h, Expression levels of OsProT1 (e, g) and OsProT3 (f, h) in response to salt stress or cadmium treatment. Rice plants were grown hydroponically for about 2 weeks using Yashida solution, and then exposed to Yoshida solution (CK) or Yoshida solution without NH4NO3 (No N), with 10 mM NH4NO3 (HN), with 50 μM CdCl2 (Cd) or with 100 mM NaCl (Na) for 2 days. Roots and shoots were harvested for RNA extraction and detection of OsProTs expression level. Values are means ± SD, n = 3. Statistical significance was tested by two-tailed Student’s t tests. Differences were dseemed significant at P < 0.05 (*) and extremely significant at P < 0.01 (**)


The accumulation of plant compatible osmolytes, such as Pro and GABA, in response to stress is frequently observed, which is mainly attributed to a combination of increased synthesis and decreased degradation (Lehmann et al. 2010; Shelp et al. 2012; Kaur and Asthir 2015). Meanwhile, abundant evidence has proven that transport of these compatible osmolytes also plays important roles (Igarashi et al. 2000; Lehmann et al. 2010; Shelp et al. 2012). However, the transporters involved in transporting Pro and GABA are largely unknown.

A previous study reported that OsProT2 transports Pro when expressed in Xenopus oocytes (Igarashi et al. 2000). In this study, we characterized the other two OsProT members, OsProT1 and OsProT3, as functional transporters for Pro and GABA. AtProT1–3, HvProT2 and LeProTl were previously identified as efficient transporters for Pro, glycine betaine and GABA (Schwacke et al. 1999; Grallath et al. 2005; Fujiwara et al. 2010). Rice lacks the enzyme requirement for glycine betaine biosynthesis; thus, rice likely does not accumulate and transport glycine betaine (Rathinasabapathi et al. 1993). When expressed in yeast, OsProT1 and OsProT3 specifically mediated the transport of Pro and GABA (Figs. 3, 4 and 5). However, the affinity for Pro was different between the individual transporters (Fig. 5). OsProT3 showed a higher affinity for Pro than that of OsProT1, and they are both lower than that of the three AtProTs with Kmapp values of 0.427 ± 0.017 mM, 0.500 ± 0.005 mM, 0.999 ± 0.036 mM for Pro, respectively (Grallath et al. 2005).

OsProT1 and OsProT3 are both localized to the plasma membrane and function to uptake Pro and GABA from the apoplast (Fig. 2, 3 and 4). Further expression analyses indicated that OsProT1, OsProT3 and OsProT2 play different roles within rice plants. The high expression of OsProT1 in leaf sheath at the vegetative stage (Fig. 6a) suggests that OsProT1 might uptake Pro and GABA as nutrition for seeding growth. OsProT2 might be involved in Pro and GABA remobilization from flag leaf blade, as it shows much higher expression in flag leaf blade than in other tissues (Additional file 1: Figure S2). OsProT3 likely contributes to more physiological processes due to its high expression in more tissues at different stages (Fig. 6b). Consistently, ProTs in Arabidopsis also exhibit similar substrate specificity but different expression patterns (Grallath et al. 2005). AtProT1 is expressed mainly in phloem or phloem parenchyma throughout the whole plant, while AtProT2 is localized in the roots, and AtProT3 is expressed in the above-ground portions of plants (Grallath et al. 2005; Lehmann et al. 2011). In addition to ProTs, evidence indicates that AtAAP members also exhibit difference in tissue expression patterns which guarantees their unique functions in Arabidopsis (Tegeder and Rentsch 2010; Tegeder 2012; Tegeder and Masclaux-Daubresse 2018).

Upon exposure to salt, plants often accumulate Pro (Ueda et al. 2001; Mansour and Ali 2017; Per et al. 2017). However, gene expression data revealed that salinity hardly affects expression levels of OsProTs (Fig. 7e-h, Additional file 1: Figure S3c and d). Consistent with our results, OsProT2 was not induced by salt treatment in a previous study (Igarashi et al. 2000). Surprisingly, Cd stress induced the expression of OsProT1 and OsProT3 in shoots (Fig. 7e and f). The accumulation of Pro frequently occurs in response to heavy metal stress (Sharma and Dietz 2006; Amna et al. 2015), and high constitutive Pro content was detected in metal-tolerant plants (Sharma and Dietz 2006). Given that the transport of Pro might participate in Cd stress tolerance, as the expression of OsProT1 and OsProT3 in shoots were induced by Cd, additional investigation into Pro transport process may improve plant tolerance to Cd.


In the present study, two plasma membrane-localized OsProT members, OsProT1 and OsProT3, were characterized as functional molecular components for transporting Pro and GABA. When ectopically expressed in yeast, OsProT1 and OsProT3 specifically mediated the uptake of Pro and GABA, and both exhibited low affinity for transporting Pro. OsProT1 and OsProT3 might function in differentially physiological processes, including stress tolerance, based on their differential expression patterns. Our work identified new molecular components for controlling the transport of Pro and GABA, and provides new clues to improve stress tolerance in rice by manipulating these transporters.

Materials and methods

Plant material and growth conditions

Uniformly germinated seeds (Oryza sativa L. var. Nipponbare) were cultivated in 96-well plates with removed bottoms (Li et al. 2015) and were then grown hydroponically in Yoshida solution (Adjust pH to 5.8, refreshed every 2 d) at 28 °C, approximately 60% humidity and a 16-h-light/8-h-dark photoperiod. 14-day-old seedlings were further treated for the analysis of gene expression. Yoshida solution without NH4NO3 or containing 10 mM NH4NO3 was used for nitrogen-starvation or high-nitrogen experiments, respectively. Yoshida solution with 50 μM CdCl2 or 100 mM NaCl was used for abiotic stress treatments.

To determine gene expression at the reproductive stage, 3-week-old rice seedlings were transplanted into flooded soil in pots with two seedlings per hill. Soil properties were pH =6.66, organic matter = 48.51 g·kg− 1, total N = 2.2 g·kg− 1, total P = 0.8 g·kg− 1, total K = 6.32 g·kg− 1, available N = 123.24 mg·kg− 1, available P = 26.04 mg·kg− 1, and available K = 118.19 mg·kg− 1. Fertilizers used were urea for N at dose of 34.5 g·m− 2, single superphosphate for P at dose of 50 g·m− 2, and potassium chloride for K at doses of 20 g·m− 2. Different tissues at reproductive stage were collected for further RNA extraction.

Radial tree construction and multiple alignments of OsProTs

OsProT protein sequences were obtained ( according to accession numbers LOC_Os01g68050.1 for OsProT1, LOC_Os03g44230.1 for OsProT2, and LOC_Os07g01090.1 for OsProT3 and were then aligned using CLUST W with default parameters. The homologous sequences in other species were obtained via blasting on the NCBI database using OsProT sequences as references. The phylogenetic tree of ProT proteins was constructed by (Lemoine et al. 2019) with 1000 bootstrap replications using the default parameters after removing redundant sequences and selecting representative splice forms of the same gene.

Functional Analysis of OsProTs in 2210α

Coding sequences of OsProT1 and OsProT3 were amplified (primers are listed in Additional file 1: Table S1) from cDNA template of Nipponbare followed by cloning into the p426GPD vector with the BamH1 and EcoR1 restriction sites, leading to the final p426GPD-OsProT1 and p426GPD-OsProT3 constructs, respectively. p426GPD-OsProT1, p426GPD-OsProT3 and the empty vector p426GPD were separately transformed into mutant yeast 2210α cells as previously described (Elble 1992). Functional complementation assays were performed as described (Fischer et al. 2002; Besnard et al. 2016) with minor modifications. Yeast cells were grown to log phase using SD medium containing 3 mM (NH4)2SO4. Then, cells were collected, rewashed, diluted to an OD600 of 0.8 in sterile water, and spotted onto SD plates containing indicated L-amino acid as the sole nitrogen source at dose of 3 mM. The cells were then grown for about 4 d before being photographed. For 15N-Pro uptake assays, 1.5 mM 15N labeled L-Pro (99 atom %) was added to the culture after yeast cells had reached log phase, and the cells were collected at 0 min, 15 min and 30 min. Then, the cells were immediately washed three times by ultrapure water and dried at 80 °C for 24 h. 15N retained in the cells was measured as previously described (He et al. 2017) using a continuous- flow isotope ratio mass spectrometer coupled to a carbon nitrogen elemental analyzer.

Determination of Kmapp for Pro by Yeast Uptake Assay

Analyses of Kmapp were performed as described previously (Hsu et al. 1993; Hirner et al. 2006; Wang and Tsay 2011) with minor modifications. Yeast cells expressing OsProT1 or OsProT3 were cultured with SD medium containing 3 mM (NH4)2SO4 until the OD600 reached 0.8. Then, the cells were cultured with SD medium containing different concentrations of 15N-Pro ranging from 0.25 mM to 40 mM for 10 min. The collection of cells and determination of 15N contents were performed as described above. The curves and the Kmapp values were obtained by fitting to the Michaelis-Menten equation in the SigmaPlot 12.0 program.

Subcellular Localization Analysis of OsProT1 and OsProT3

The amplified fragment of OsProT1 and OsProT3 (primers used for amplifying are listed in Additional file 1: Table S1) coding sequences were cloned in frame with eGFP into pA7-eGFP vector using Xba1 and BamH1, resulting in eGFP-OsProT1 and eGFP-OsProT3 constructs, respectively, driven by the 35S promoter. Fusion constructions were then transiently expressed in Arabidopsis protoplasts as described previously (Yoo et al. 2007). Transformed protoplasts were incubated in the dark at 22 °C overnight, and eGFP images were subsequently obtained using confocal microscopy (Olympus-FV1000) (Peng et al. 2017). The fluorescent dye Dil was used at a concentration of 10 μM to indicate the plasma membrane (Wang et al. 2019).

Quantitative RT-PCR (Reverse Transcription Polymerase Chain Reaction)

RNA was extracted using TRIzol reagent (Invitrogen, 15,596,026) as previously described (Meng et al. 2016). First-strand cDNA was synthesized using cDNA Synthesis Kit (Vazyme, R212), and quantitative RT–PCR was performed using SYBR Green with a StepOnePlus instrument (Applied Biosystems). OsACTIN1 (LOC_Os03g50885.1) was selected as internal reference gene. Primers used for assays are all listed in Additional file 1: Table S1. The different samples used for the qPCR are biological replicates, and relative expression levels are the expression of OsProTs normalized to that of OsACTIN1 using formula Ratio = 2 (Ct_OsActin − Ct_OsProT).

Availability of data and materials

All data generated or analyzed during this study are included in this published article and its supplementary information files.



Amino acid permease


Amino acid transporter


Aluminum-Activated Malate Transporter


1,1′- dioctadecyl- 3,3,3′,3′- tetramethylindocarbocyanine perchlorate


Enhanced green fluorescent protein


Empty vector


γ-aminobutyric acid

Kmapp :

Apparent Km




Proline transporter


Quantitative real time polymerase chain reaction


  1. Amna MS, Syed JH, Munis MF, Chaudhary HJ (2015) Phyto-extraction of nickel by linum usitatissimum in association with glomus intraradices. Int J Phytoremediation 17:981–987

  2. Ashraf M, Foolad MR (2007) Roles of glycine betaine and proline in improving plant abiotic stress resistance. Environ Exp Bot 59:206–216

  3. Besnard J, Pratelli R, Zhao C, Sonawala U, Collakova E, Pilot G, Okumoto S (2016) UMAMIT14 is an amino acid exporter involved in phloem unloading in Arabidopsis roots. J Exp Bot 67:6385–6397

  4. Bialczyk J, Lechowski Z, Dziga D (2004) Composition of the xylem sap of tomato seedlings cultivated on media with HCO3 and nitrogen source as NO3 or NH4 +. Plant Soil 263:265–272

  5. Biancucci M, Mattioli R, Forlani G, Funck D, Costantino P, Trovato M (2015) Role of proline and GABA in sexual reproduction of angiosperms. Front Plant Sci 6:680

  6. Bown AW, Shelp BJ (2016) Plant GABA: not just a metabolite. Trends Plant Sci 21:811–813

  7. Chen J, Wu J, Lu Y, Cao Y, Zeng H, Zhang Z, Wang L, Wang S (2016) Molecular cloning and characterization of a gene encoding the proline transporter protein in common bean (Phaseolus vulgaris L.). Crop Journal 4:384–390

  8. Chung I, Bown AW, Shelp BJ (1992) The production and efflux of 4-aminobutyrate in isolated mesophyll cells. Plant Physiol 99:659–664

  9. Elble R (1992) A simple and efficient procedure for transformation of yeasts. Biotechniques 13:18–20

  10. Fischer WN, Loo DD, Koch W, Ludewig U, Boorer KJ, Tegeder M, Rentsch D, Wright EM, Frommer WB (2002) Low and high affinity amino acid H+-cotransporters for cellular import of neutral and charged amino acids. Plant J 29:717–731

  11. Fujiwara T, Mitsuya S, Miyake H, Hattori T, Takabe T (2010) Characterization of a novel glycinebetaine/proline transporter gene expressed in the mestome sheath and lateral root cap cells in barley. Planta 232:133–143

  12. Funck D, Winter G, Baumgarten L, Forlani G (2012) Requirement of proline synthesis during Arabidopsis reproductive development. BMC Plant Biol 12:1471–2229

  13. Girousse C, Bournoville R, Bonnemain JL (1996) Water deficit-induced changes in concentrations in proline and some other amino acids in the phloem sap of alfalfa. Plant Physiol 111:109–113

  14. Grallath S, Weimar T, Meyer A, Gumy C, Suter-Grotemeyer M, Neuhaus JM, Rentsch D (2005) The AtProT family. Compatible solute transporters with similar substrate specificity but differential expression patterns. Plant Physiol 137:117–126

  15. He YN, Peng JS, Cai Y, Liu DF, Guan Y, Yi HY, Gong JM (2017) Tonoplast-localized nitrate uptake transporters involved in vacuolar nitrate efflux and reallocation in Arabidopsis. Sci Rep 7:6417

  16. Hirner A, Ladwig F, Stransky H, Okumoto S, Keinath M, Harms A, Frommer WB, Koch W (2006) Arabidopsis LHT1 is a high-affinity transporter for cellular amino acid uptake in both root epidermis and leaf mesophyll. Plant Cell 18:1931–1946

  17. Hsu LC, Chiou TJ, Chen L, Bush DR (1993) Cloning a plant amino acid transporter by functional complementation of a yeast amino acid transport mutant. Proc Natl Acad Sci U S A 90:7441–7445

  18. Igarashi Y, Yoshiba Y, Takeshita T, Nomura S, Otomo J, Yamaguchi-Shinozaki K, Shinozaki K (2000) Molecular cloning and characterization of a cDNA encoding proline transporter in rice. Plant Cell Physiol 41:750–756

  19. Jaillon O, Aury JM, Noel B, Policriti A, Clepet C, Casagrande A, Choisne N, Aubourg S, Vitulo N, Jubin C et al (2007) The grapevine genome sequence suggests ancestral hexaploidization in major angiosperm phyla. Nature 449:463–467

  20. Kaur G, Asthir B (2015) Proline: a key player in plant abiotic stress tolerance. Biol Plant 59:609–619

  21. Kishor P, Hong Z, Miao GH, Hu C, Verma D (1995) Overexpression of 1-pyrroline-5-carboxylate synthetase increases proline production and confers osmotolerance in transgenic plants. Plant Physiol 108:1387–1394

  22. Lehmann S, Funck D, Szabados L, Rentsch D (2010) Proline metabolism and transport in plant development. Amino Acids 39:949–962

  23. Lehmann S, Gumy C, Blatter E, Boeffel S, Fricke W, Rentsch D (2011) In planta function of compatible solute transporters of the AtProT family. J Exp Bot 62:787–796

  24. Lemoine F, Correia D, Lefort V, Doppelt-Azeroual O, Mareuil F, Cohen-Boulakia S, Gascuel O (2019) new generation phylogenetic services for non-specialists. Nucleic Acids Res 47:W260–W265

  25. Li XM, Chao DY, Wu Y, Huang XH, Chen K, Cui LG, Su L, Ye WW, Chen H, Chen HC, Dong NQ, Guo T, Shi M, Feng Q, Zhang P, Han B, Shan JX, Gao JP, Lin HX (2015) Natural alleles of a proteasome α 2 subunit gene contribute to thermotolerance and adaptation of African rice. Nat Genet 47:827–833

  26. Lu YE, Song ZY, Lu K, Lian XM, Cai HM (2012) Molecular characterization, expression and functional analysis of the amino acid transporter gene family (OsAATs) in rice. Acta Physiol Plant 34:1943–1962

  27. Mansour MMF, Ali EF (2017) Evaluation of proline functions in saline conditions. Phytochemistry 140:52–68

  28. Mattioli R, Biancucci M, El Shall A, Mosca L, Costantino P, Funck D, Trovato M (2018) Proline synthesis in developing microspores is required for pollen development and fertility. BMC Plant Biol 18:356

  29. Mattioli R, Biancucci M, Lonoce C, Costantino P, Trovato M (2012) Proline is required for male gametophyte development in Arabidopsis. BMC Plant Biol 12:236

  30. Mekonnen DW, Flugge UI, Ludewig F (2016) Gamma-aminobutyric acid depletion affects stomata closure and drought tolerance of Arabidopsis thaliana. Plant Sci 245:25–34

  31. Meng S, Peng JS, He YN, Zhang GB, Yi HY, Fu YL, Gong JM (2016) Arabidopsis NRT1.5 mediates the suppression of nitrate starvation-induced leaf senescence by modulating foliar potassium level. Mol Plant 9:461–470

  32. Peng JS, Ding G, Meng S, Yi HY, Gong JM (2017) Enhanced metal tolerance correlates with heterotypic variation in SpMTL, a metallothionein-like protein from the hyperaccumulator Sedum plumbizincicola. Plant Cell Environ 40:1368–1378

  33. Per TS, Khan NA, Reddy PS, Masood A, Hasanuzzaman M, Khan MIR, Anjum NA (2017) Approaches in modulating proline metabolism in plants for salt and drought stress tolerance: Phytohormones, mineral nutrients and transgenics. Plant Physiol Biochem 115:126–140

  34. Ramesh SA, Tyerman SD, Xu B, Bose J, Kaur S, Conn V, Domingos P, Ullah S, Wege S, Shabala S, Feijo JA, Ryan PR, Gilliham M (2015) GABA signalling modulates plant growth by directly regulating the activity of plant-specific anion transporters. Nat Commun 6:7879

  35. Rathinasabapathi B, Gage DA, Mackill DJ, Hanson AD (1993) Cultivated and wild Rices do not accumulate glycinebetaine due to deficiencies in two biosynthetic steps. Crop Sci 33:534–538

  36. Rentsch D, Hirner B, Schmelzer E, Frommer WB (1996) Salt stress-induced proline transporters and salt stress-repressed broad specificity amino acid permeases identified by suppression of a yeast amino acid permease-targeting mutant. Plant Cell 8:1437–1446

  37. Scholz SS, Reichelt M, Mekonnen DW, Ludewig F, Mithofer A (2015) Insect herbivory-elicited GABA accumulation in plants is a wound-induced, direct, systemic, and jasmonate-independent defense response. Front Plant Sci 6:1128

  38. Schwacke R, Grallath S, Breitkreuz KE, Stransky E, Stransky H, Frommer WB, Rentsch D (1999) LeProT1, a transporter for proline, glycine betaine, and gamma-amino butyric acid in tomato pollen. Plant Cell 11:377–392

  39. Sharma SS, Dietz KJ (2006) The significance of amino acids and amino acid-derived molecules in plant responses and adaptation to heavy metal stress. J Exp Bot 57:711–726

  40. Shelp BJ, Bown AW, McLean MD (1999) Metabolism and functions of gamma-aminobutyric acid. Trends Plant Sci 4:446–452

  41. Shelp BJ, Mullen RT, Waller JC (2012) Compartmentation of GABA metabolism raises intriguing questions. Trends Plant Sci 17:57–59

  42. Spoljarevic M, Agic D, Lisjak M, Gumze A, Wilson ID, Hancock JT, Teklic T (2011) The relationship of proline content and metabolism on the productivity of maize plants. Plant Signal Behav 6:251–257

  43. Stines AP, Naylor DJ, Hoj PB, van Heeswijck R (1999) Proline accumulation in developing grapevine fruit occurs independently of changes in the levels of 1-pyrroline-5-carboxylate synthetase mRNA or protein. Plant Physiol 120:923

  44. Szabados L, Savoure A (2010) Proline: a multifunctional amino acid. Trends Plant Sci 15:89–97

  45. Tegeder M (2012) Transporters for amino acids in plant cells: some functions and many unknowns. Curr Opin Plant Biol 15:315–321

  46. Tegeder M, Masclaux-Daubresse C (2018) Source and sink mechanisms of nitrogen transport and use. New Phytol 217:35–53

  47. Tegeder M, Rentsch D (2010) Uptake and partitioning of amino acids and peptides. Mol Plant 3:997–1011

  48. Ueda A, Shi W, Sanmiya K, Shono M, Takabe T (2001) Functional analysis of salt-inducible proline transporter of barley roots. Plant Cell Physiol 42:1282–1289

  49. Wang H, Ji F, Zhang Y, Hou J, Liu W, Huang J, Liang W (2019) Interactions between hydrogen sulphide and nitric oxide regulate two soybean citrate transporters during the alleviation of aluminium toxicity. Plant Cell Environ 42:2340–2356

  50. Wang YY, Tsay YF (2011) Arabidopsis nitrate transporter NRT1.9 is important in phloem nitrate transport. Plant Cell 23:1945–1957

  51. Weibull J, Ronquist F, Brishammar S (1990) Free amino acid composition of leaf exudates and phloem sap : a comparative study in oats and barley. Plant Physiol 92:222–226

  52. Yoo SD, Cho YH, Sheen J (2007) Arabidopsis mesophyll protoplasts: a versatile cell system for transient gene expression analysis. Nat Protoc 2:1565–1572

  53. Zhao H, Ma H, Yu L, Wang X, Zhao J (2012) Genome-wide survey and expression analysis of amino acid transporter gene family in rice (Oryza sativa L.). PLoS One 7:15
